Name: Heavy duty CNC fixed length single head cutting saw
Brand: HSformwork

Description

Main features and functions:

1. Sawing product thickness 4-8 millimeters
2. Sawing width * height: 3000 * 65MM
3. Install a reasonable pressing device as required
4. Saw blade angle 90-45
5. Increase PP board cutting and enlarge the tabletop
6. Equipped with digital display device at any angle

Main technical parameters:
Material table area: 3000 * 320 mm
Main motor power: 5.5 KW
Spindle speed: 4200r/min
Maximum cutting stroke: 3000mm
Maximum size of saw blade: 355mm
Machine tool dimensions: 3150X2500X1300 mm
Machine weight: 980KG

Integration with Milling and Workflow Systems
In modern production lines, precision cutting equipment such as this CNC fixed‐length saw often works downstream from advanced milling machines such as the Vertical dual workpiece CNC multi head milling machine HS-1287. After the HS-1287 performs multi‐head milling or slotting operations on aluminium profiles (ensuring accurate geometry and finish), the fixed-length single head saw is used to separate lengths and cut profiles to size under strictly controlled conditions. This sequence ensures that the material fed into cutting has already been machined to tolerance, enabling the saw to deliver high accuracy, consistent lengths and minimal waste. By linking the milling system and cutting saw into a streamlined workflow, manufacturers can reduce manual handling, improve throughput, and deliver higher repeatability for downstream assembly.

Precision and Stability
This saw machine features a heavy-duty frame and engineered feed mechanisms to reduce vibration and maintain alignment during high-speed cutting. The digital display device assists operators in setting the cut length and angle with high accuracy; the inclusion of the pressing device ensures the material remains firmly positioned during the cut, reducing movement or deflection. These features are especially important when cutting long aluminium profiles or sections where even slight deviation can affect downstream assembly or installation. The fixed-length CNC positioning ensures consistent output lengths across large batches, improving quality control and reducing scrap.

Industrial Grade Build & Operation
Designed for continuous factory use, the machine’s structural design (nearly 1 ton weight) provides the rigidity required for repeat accuracy. The 5.5 kW motor and 4200 r/min spindle speed ensure the cutting blade has sufficient power and rotational speed for efficient aluminium profile cutting, even in larger sections. The large saw-blade size (φ355 mm) further supports the machine’s capacity to handle heavier and wider profiles. The table size supports long material feeds, and the optional pressing device along with the digital angle display enhance operator usability and reduce setup time.

Versatility of Application
This cutting saw is not restricted to aluminium formwork alone—it is well suited for any industrial aluminium profile manufacturing operation, curtain wall frame cutting, door/window profile production, photovoltaic solar mounting frame manufacture, or bespoke aluminium structure processing. With the fixed-length cutting feature, users can produce large volumes of identical length parts for assembly lines, reducing cycle times and ensuring consistent output. The ability to set angle cuts (90°–45°) and install a pressing device further adds flexibility to the machine’s application scope.

Product Advantages

High-Precision Fixed-Length Cutting:The CNC fixed‐length positioning system ensures that every cut is precisely controlled, delivering consistent output lengths across large batches. This greatly reduces scrap and rework, especially when used after precision milling equipment such as the Vertical dual workpiece CNC multi head milling machine HS-1287.
Industrial-Grade Build for Durability:With a nearly 1 ton machine weight and a robust 5.5 kW motor driving a φ355 mm saw blade at 4 200 r/min, the machine is engineered for heavy‐duty industrial usage. The stable frame minimizes vibration, maintaining cut accuracy even under high throughput.
Flexible Cutting Angles & Material Sizes:Allows cutting angles between 90° and 45°, accommodating mitre or straight cuts. Material size capacity (up to 3000×65 mm) facilitates long aluminium profiles and large formwork panels. The optional pressing device and digital display make setup fast and reliable.
Seamless Workflow Integration:When integrated in a line with the HS-1287 milling machine, this cutting saw becomes part of an efficient production chain: milling → precision profiling → fixed length cutting. This synergy boosts productivity, keeps cycle times low and ensures high quality from raw profile to final cut length.
Operator Efficiency & Reduced Maintenance:Digital displays and pressing devices simplify operator setup and reduce manual measurement errors. With stable operation and minimal vibration, wear and maintenance costs are lower, while throughput remains high.
