Engineered for the rigorous demands of aluminum template manufacturing. The YLT-150T combines 150 tons of hydraulic force with PLC automated precision to deliver consistent, burr-free punching for large-scale production lines.
The YLT-150T Hydraulic Large Row Punch is a specialized industrial machine designed for the aluminum template processing equipment sector. It utilizes a high-pressure hydraulic transmission system (1500KN) to execute multi-hole punching operations on aluminum profiles simultaneously. Unlike mechanical presses, this hydraulic unit offers adjustable stroke control, overload protection, and consistent pressure application, making it critical for ensuring the dimensional accuracy required in modern construction formwork assembly.
Close-up view of the hydraulic cylinder housing and guide pillars.
| Nominal Pressure | 1500 KN (150 Tons) |
| Motor Power | 11 kW / 15 kW (Configurable) |
| Max Stroke | Customizable (Standard 150mm) |
| Control System | PLC + Foot Pedal Actuation |
Need specific dimensional drawings? Visit our Product Page for full schematics →
"We upgraded from mechanical punches to the YLT-150T. The hydraulic stability significantly reduced our burr rate on 4mm aluminum profiles."
Production Director
Aluminum Formwork Plant, Vietnam
"The structural rigidity of this 150T machine is impressive. It handles continuous shifts without overheating. Good spare parts availability."
Maintenance Engineer
Construction Equipment Supplier, Saudi Arabia
"Essential for our U-profile production. The row punching is precise, making site assembly much faster for our end clients."
Factory Manager
Formwork Mfg, Mexico
Standard lead time is 15-20 working days. For units requiring custom voltage (e.g., 220V/60Hz) or specific die sets, please allow an additional 5-7 days.
The basic unit includes one standard set of dies. However, since aluminum formwork profiles vary (C-profile, U-profile, Flat tie), we recommend providing your profile drawings so we can customize the die set for you.
We recommend #46 anti-wear hydraulic oil for standard operating temperatures. For tropical climates, #68 may be more appropriate to maintain viscosity.
Yes, the YLT-150T features PLC controls which can be synced with automatic feeding tables and sawing machines for a continuous production line workflow.
We offer a 12-month warranty on main components (hydraulic pump, motor, cylinder). Consumable parts like punching pins and seals are excluded but can be supplied at cost.
The machine is wrapped in protective film and secured within a standard export-grade wooden crate or steel pallet to prevent movement and corrosion during sea freight.
